Products

CJSS

Product Information

Accumulator absorbs the pressure fluctuation so that it prevents system pressure from variation due to the high or low abnormal pressure.

Usable fluid:
ISO-VG-32 hydraulic oil equivalent to ISO viscosity grade.

Ordering Indication

（eg.CJSS-402HSB）

CJSS	Series	CJSS
4	Standard Operating Pressure	2: 2MPa, 3: 3MPa, 4: 4MPa
02	Amount of Discharge Oil	02: 2.5cm³, 05: 5cm³, 10: 10cm³
H	Mounting Direction	H: Horizontal Mounting(selected for piping method: C/S/GC/GS), V: Vertical Mounting
S	Piping Method	C: Piping Option(BSPP Thread(G-Thread), S: Piping Option(BSPT (RC-Thread), G: Gasket Option, GC: Gasket + Piping Option(BSPP Thread(G-Thread), GS: Gasket + Piping Option(BSPT (RC- Thread)
B	Piping Direction	A: Top Piping, B: Side Piping(*for V: Vertical Mounting, Piping Direction is ''Blank"; for H: Horizontal Mounting and Piping Method: G, Piping Direction is "Blank")

Product Information

Model	CJSS-202	CJSS-205	CJSS-210	CJSS-302	CJSS-305	CJSS-310	CJSS-402	CJSS-405	CJSS-410
Standard Operating Pressure(Mpa)	2	2	2	3	3	3	4	4	4
Withstanding Pressure(Mpa)	14	14	14	14	14	14	14	14	14
Discharge Oil Capacity (cm³)	2.5	5	10	2.5	5	10	2.5	5	10
Absorbing Capacity (cm³)	1	2	4	1	2	4	1	2	4
Compression Factor(β)(MPa/cm³)	0.4	0.31	0.16	0.4	0.33	0.17	0.49	0.37	0.18
Weight(kg)	0.8	1	1.7	0.8	1.1	1.7	0.8	1.1	2
Operating Temperature(°C)	0~+70	0~+70	0~+70	0~+70	0~+70	0~+70	0~+70	0~+70	0~+70
